Victron Argofet 100-2 100A 2 Batteries FET Isolator
Victron ARGOFET Isolator 100-2
The Victron ARGOFET Isolator 100-2 (MPN ARG100201020R) is the ideal solution for all who want to efficiently supply two separate battery circuits from a single power source. With a maximum charging power of up to 100A, this isolator is suitable for both alternators and chargers.
Advantages Of The ARGOFET Isolator
A significant advantage of the ARGOFET Isolator is that the battery banks are not connected to each other. This means they can neither discharge each other nor influence each other. This ensures optimal use of the batteries and extends their lifespan.
Technical Features
Show Technical Details
- Maximum Charging Current: 100A
- Connections for 2 Battery Circuits
- Voltage Drop: less than 0.02V at low currents, 0.1V at high currents
- 5 Years Warranty on proven Victron Quality
Highest Efficiency
In contrast to conventional battery isolation diodes, FET Isolators generate almost no voltage drop. This means that a voltage increase is not necessary, which significantly simplifies installation and operation. However, pay attention to short cable lengths and sufficient cable cross-sections to maximize efficiency.
Example For Voltage Drops
A practical example: With a 100A current, a cable length of 10 m and a cable cross-section of 50 mm², the voltage drop is only 0.26 Volts. With 5 m of cable and 10 mm², a 50A current causes a loss of 0.35 Volts. This makes the FET Isolators the most efficient charging current distributors on the market.
Scope Of Delivery
- 1x Victron ARG100201020R Argofet 100-2 FET Isolator 100A / 2 Batteries
- 1x Instruction Manual
