Victron

Victron MultiPlus 12/500/20-16 230V

€350,48
Verfügbar: Delivery within 1-3 business days

Victron Energy MultiPlus 12/500/20-16 (PMP121500000)

The MultiPlus 12/500/20-16 from Victron Energy is the perfect solution for your power supply. With a continuous power of 500W at 230V and 50Hz, this sine wave inverter transforms the 12V DC voltage of your battery into a high-quality 230V AC sine wave voltage. Additionally, it is equipped with a 20A battery charger and a 16A transfer switch, making it a versatile and cost-effective choice for numerous applications.

Essential Performance Features

Technical Specifications
  • Continuous Power: 500W
  • Peak Power: 900W
  • Battery Voltage: 12V
  • Sine Wave Inverter with 16A Transfer Switch
  • 20A Battery Charger for Optimal Performance

The MultiPlus 12/500/20 offers a reliable power supply with purest sine wave voltage and stable frequency. It can be used as an uninterruptible power supply (UPS), which means that in the event of a power outage, it immediately switches to inverter operation. This happens in less than 20 milliseconds, so important devices like computers can continue to run without interruption.

Programmable Relay

An additional highlight is the programmable multi-function relay, which functions as an alarm relay by default. However, you can customize it for many different functions, e.g., as a start relay for a generator.

Control And Configuration

Simple configuration is done via a 3-position switch (DIP switch) directly on the device, where the maximum AC charging current can also be set.

Battery Charger

The powerful, 4-stage battery charger offers an adaptive charging characteristic that automatically adjusts to different battery types. This includes:

  • Constant Current Phase ("bulk")
  • Constant Voltage Phase ("absorption")
  • Float Charge Phase ("float")
  • Storage Voltage Phase ("storage")

Additional functions such as temperature compensation and a battery-saving mode help to extend the lifespan of your batteries and minimize their aging.

Diverse Application Possibilities

The MultiPlus 12/500/20 is suitable for both mobile and stationary applications and can be used in grid-connected self-consumption systems. This means that it only draws power from the grid when the battery capacity is insufficient.

Scope Of Delivery

  • 1x Victron Multi CMP125010000 12/500/20
  • 1x User Manual

Discover the quality and reliability of the Victron MultiPlus 12/500/20 and enjoy an uninterrupted and secure power supply for your needs!
